Full Automatic Metal Cutting Band Saw Machine
MODEL: GZ4240
APPROVALS: CE, ISO9001
STYLE: Horizontal
TYPE: Double Column
CONTROL: PLC Automatic
Key Specifications:
Cutting capacity | (Dia.) | 320 |
(width) | 320 | |
Blade speed | 30/46/58/83(m/min) | |
Blade Size | 1.1x34x4115(mm) | |
Main Motor | 4(kw) | |
Hydraulic Motor | 0.75(kw) | |
Machine Size(LxWxH) | 2100x2000x1350(mm) | |
Workpiece Clamping | Hydraulic | |
Main Features:
| PLC program control, setting the cutting process. |
| Grating position feeding length, single-precision feed control within 0.2mm. |
| Processing size can be set to 1~5 groups. |
| Each group can be set once the feed length 50000mm. |
| Each group can be set once the number of processing elements is 1-999. |
| Jaws around the same time release / clamping jaws easy to wear. |
| Circulating hydraulic oil cooling system, the oil temperature is not easy to rise. |
| Automatic saw blade sweep crumbs device to prevent the accumulation of sawdust in the jagged,effective protection band saw blades. |
| Broken belt protection function, when the saw blade breaks or cassette, the machine can automatically shut down to protect the machine and workpiece. |
| Clamping detachable hydraulic system that allows a plurality of multilayer workpiece while cutting. |
mainly be used for cutting black metal ,non ferrous metal ,plastic and other non-metal materials .
About us
our company Zhejiang Aolinfa machine tool Co. Ltd. (former zhejiang jinyun huadong machine tool plant) was established in 1988. it is a band saw enterprise manufacturing horizontal, vertical, double column and planer-type metal band sawing machine . covers an area over 20,000 square meters and has total assets over RMB90 million .it has be engaged in band saw manufacturing for decades and accumulate rich band saw manufacturing experience and strong technology designing capacity .
9 years export experience bring the best service to you .we have more than 9 years export expereience. our products have been exported to Signapore,Russia,Qutar,AE, Ethiopia,Hungary,egypt,etc
